A compact night vision monocular built around a Gen 3+ Alpha-grade image intensifier tube with manual gain control. It is designed for handheld use, helmet-mount setups, and mounting in front of a photo or video camera lens for night imaging.
At the core is a Gen 3+ Alpha tube with green phosphor and a resolution of 64–72 lp/mm. Manual gain (MG) lets the operator match image brightness to ambient light, while bright light cut-off protects the tube and the operator’s vision from sudden flashes.
The NYX-14C comes with a universal camera adapter that adjusts along three axes and mounts to a tripod via a standard ¼" thread. An interchangeable eyepiece allows switching from imaging to visual observation: with it, the device works as a 2x monocular. The waterproof housing is built for use in a range of conditions.
Key Advantages
- Gen 3+ Alpha tube with green phosphor, 64–72 lp/mm resolution
- Manual gain for different lighting levels
- Bright light cut-off protects the tube and the operator’s vision
- Universal photo/video camera adapter included
- Interchangeable eyepiece: switch to 2x monocular mode
- 10,000-hour tube life
- Waterproof housing
- Handheld use and compatibility with helmet mounts
Technical Specifications
| Parameter | Value |
|---|---|
| Device type | Night vision monocular for photo and video cameras |
| Tube generation | Gen 3+ (Alpha) |
| Phosphor type | Green phosphor |
| Gain control | Manual (MG) |
| Resolution | 64–72 lp/mm |
| Signal-to-noise ratio (SNR) | 26 (typical) |
| Tube life | 10,000 hours |
| Bright light cut-off | Yes |
| Interchangeable eyepiece | Yes (2x monocular mode) |
| Housing | Waterproof |
Package Contents
- ARMASIGHT NYX-14C night vision monocular
- Universal camera adapter
- Standard 20 mm eyepiece
- 38 mm photography eyepiece
- Lens tissue
Applications
Night photo and video capture, observation, handheld use, helmet-mounted operation.
